Technical data
Type：FT- |
1KW |
2KW |
3KW |
4KW |
5KW |
6KW |
8KW | |
Rated power |
1000W |
2000W |
3000W |
4000W |
5000W |
6000W |
8000W | |
Battery |
Rated voltage |
12VD/24VDC /48VDC |
24VDC/48VDC | 24/48/96 VDC |
48/96VDC |
48/96VDC | ||
AC Charge current |
30A（default）-C0-C6 can be set | |||||||
Battery type |
U0-U7 can be set | |||||||
AC Input |
Voltage range |
85-138VAC;170-275VAC | ||||||
Frequency |
45-65Hz | |||||||
Output |
Voltage range |
110VAC;220VAC；±5%( Inverter mode) | ||||||
Frequency |
50/60Hz±1%( automatic identification) | |||||||
Output wave |
Pure sine wave | |||||||
Switching time |
＜10ms( typical load) | |||||||
Efficiency |
＞85%（80% Resistance load） | |||||||
Overload |
110-120% power load 30S protect；＞160%/300ms； | |||||||
Protection |
Battery overvoltage/lowvoltage, overload, short circuit protection, overtemperature protection, etc. | |||||||
Operating ambient temperature |
-20℃~+40℃ | |||||||
Storage ambient temperature |
-25℃ - +50℃ | |||||||
Operating/Storage ambient |
0-90% No condensation | |||||||
Machine Size: L*W*H (mm) |
486*247*179 |
555*307*189 |
653*332*260 | |||||
Package size: L*W*H（mm） |
550*310*230 |
640*370*240 |
715*365*310 | |||||
Net weight/Gross weight(Kg) |
11/13 |
14/16 |
16/18 |
23/27 |
26/30 |
30/34 |
53/55 | |
